Oscilloscope 184A

• Country
• United States of America (USA)

• Manufacturer / Brand
• Hewlett-Packard, (HP); Palo Alto, CA

• Year
• 1970 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 225586

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 5083-3770

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 115 / 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Oscilloscope 184A - Hewlett-Packard, HP; Palo Alto

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 200 x 289 x 540 mm / 7.9 x 11.4 x 21.3 inch

• Notes

• Labor-Speicheroszilloskop für Echtzeitanwendungen bis 100MHz und Sampling bis 18GHz, je nach optionalen Einschüben. Sehr gute Kombinationen: mit Einschub 1810A als 1GHz 2-Kanal-Sampling Oszilloskop (siehe Bild), oder mit Einschüben 1804A / 1825A als 50MHz 4-Kanal-Oszilloskop (siehe Bild).

• Net weight (2.2 lb = 1 kg)
• 10.9 kg / 24 lb 0.1 oz (24.009 lb)

• Source of data
• - - Manufacturers Literature

• Documents regarding this model

• Author
• Model page created by Thomas Wuwer. See "Data change" for further contributors.
