Quartz Oscillator 103-AR

Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1505338) Equipment

Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1505339) Equipment

Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1505340) Equipment

Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1505337) Equipment
Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1085060) Equipment Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1085062) Equipment
Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1085064) Equipment
Use red slider bar for more.
Quartz Oscillator 103-AR; Hewlett-Packard, HP; (ID = 1085060) Equipment
Hewlett-Packard, HP;: Quartz Oscillator 103-AR [Equipment] ID = 1085060 933x295
Select picture or schematic to display from thumbnails on the right and click for download.
For model Quartz Oscillator 103-AR, Hewlett-Packard, (HP); Palo Alto, CA:
Hewlett Packard 103AR quartz oscillator front view

Country:  United States of America (USA)
Manufacturer / Brand:  Hewlett-Packard, (HP); Palo Alto, CA
Year: 1960 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Details
Power type and voltage Alternating Current supply (AC) / 120 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Quartz Oscillator 103-AR - Hewlett-Packard, HP; Palo Alto
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 19 x 7 x 19 inch / 483 x 178 x 483 mm
Notes This unit is a temperature-compensated frequency standard with 5x10(-5) per day stability. It is first mentioned in the November 1960 Hewlett Packard Journal.
Net weight (2.2 lb = 1 kg) 16 lb (16 lb 0 oz) / 7.264 kg
Price in first year of sale 2'500.00 $
Mentioned in HP Journal November 1960

Model page created by Hank Kaczmarski. See "Data change" for further contributors.
