Szélessávú RC generátor - Wide Band RC Generator HGR 11-54
Hiradástechnika Szövetkezet (HTSZ); Budapest
- Country
- Hungary
- Manufacturer / Brand
- Hiradástechnika Szövetkezet (HTSZ); Budapest
- Year
- 1954
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 315547
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110/220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Szélessávú RC generátor - Wide Band RC Generator HGR 11-54 - Hiradástechnika Szövetkezet
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 185 x 240 x 115 mm / 7.3 x 9.4 x 4.5 inch
- Notes
-
20Hz-2MHz
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
