• Country
• Great Britain (UK)

• Manufacturer / Brand
• His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB

• Year
• 1939

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 195913

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• X23 or X24 Z21 HD23 KT2 KT2

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage and/or dry batteries / 2 & 6 & 114 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 5 Valve 3 Waveband Superhet 1400 - His Master's Voice Masters,

• Shape
• Tablemodel with Push Buttons.

• Notes
• Similar to the Marconiphone 872 battery receiver.

• Price in first year of sale
• 13.13 £

• Literature/Schematics (1)
• Trader sheet 437

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
