Rhapsody 32-46 Ch= 32

Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1887311) Radio

Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1887312) Radio
Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950032) Radio Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950033) Radio
Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950035) Radio Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950039) Radio
Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950040) Radio Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950041) Radio
Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950042) Radio Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1887322) Radio
Use red slider bar for more.
Rhapsody 32-46 Ch= 32; His Master's Voice (ID = 1950032) Radio
His Master's Voice: Rhapsody 32-46 Ch= 32 [Radio] ID = 1950032 1400x932
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rhapsody 32-46 Ch= 32, His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW:
Ebay advertisement by seller [68make] , eBay item number:121871202214 Contact Radio Museum to provide more complete photo credit information or request removal”

Country:  Australia
Manufacturer / Brand:  His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6BE6 6BA6 6AV6 6M5 6X4
Main principle Super-Heterodyne (Super in general); ZF/IF 457.5 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 220-225; 226-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
Power out
from Radiomuseum.org Model: Rhapsody 32-46 Ch= 32 - His Master's Voice HMV, H.M.V.
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 35.25 x 33.5 x 17.25 inch / 895 x 851 x 438 mm
Notes

Automatic record changer - 3-speed BSR Monarch.

Cabinet available in Walnut or Rosewood.

Net weight (2.2 lb = 1 kg) 81 lb 0 oz (81 lb) / 36.774 kg
Price in first year of sale 122.85 AUS £
Circuit diagram reference Australian Official Radio Service Manual Vol. XIII
Mentioned in "Examiner" (Tas), May 27, 1954.
Literature/Schematics (1) - - Manufacturers Literature (HMV Model Data Sheet, 32-46.)
Literature/Schematics (2) - - Manufacturers Literature (HMV Service Manual, Chassis 32.)
Literature/Schematics (3) Australian Official Radio Service Manual AORSM (Volume 13, 1955, Page 140.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
