360 ; His Master's Voice (ID = 2535567) Radio
His Master's Voice: 360 [Radio] ID = 2535567 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model 360, His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB:
The grille cloth has been replaced. Ebay UK auction item_392827837638 seller regentoneman

Country:  Great Britain (UK)
Manufacturer / Brand:  His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: VMS4B MH41 N41 U12
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 360 - His Master's Voice Masters,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 17.25 x 11 x 9 inch / 438 x 279 x 229 mm
Notes identical chassis used in Marconiphone 240 and Columbia 359.
Source of data Radio! Radio!
Literature/Schematics (1) His Master's Voice, Original Sheet 48A

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.



All listed radios etc. from His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Here you find 395 models, 283 with images and 237 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
