600 Ch= 410P; His Master's Voice (ID = 771490) Radio

600 Ch= 410P; His Master's Voice (ID = 771491) Radio

600 Ch= 410P; His Master's Voice (ID = 771492) Radio

600 Ch= 410P; His Master's Voice (ID = 771493) Radio
Use red slider bar for more.
600 Ch= 410P; His Master's Voice (ID = 771490) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1A7GT 1N5GT 1H5GT 1Q5GT
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Batteries / addl. power jack / 90 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: 600 Ch= 410P - His Master's Voice HMV, H.M.V.
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Notes As well as internal batteries, this model could be powered from an external AC mains unit type APC0223 or an external synchronous vibrator unit type APB0072. The mains unit used a 25Z6G rectifier.
Circuit diagram reference Australian Official Radio Service Manual Vol. III
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.
