653C

653C; His Master's Voice (ID = 2177942) Radio

653C; His Master's Voice (ID = 2177943) Radio

653C; His Master's Voice (ID = 2177944) Radio

653C; His Master's Voice (ID = 2177945) Radio
Use red slider bar for more.
653C; His Master's Voice (ID = 2177942) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: X63 KTW63 DH63 KT63 U50
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 195-255 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 653C - His Master's Voice Masters,
Material Wooden case
Shape Console with any shape - in general
Notes The same as the Marconiphone 653 console radio except it has the Trawler band 67-200m instead of SW 13,5 - 50m. Similar to the Marconiphone 857T console radio.
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader sheet 334

Model page created by Peter Hoddow. See "Data change" for further contributors.
