Colourmaster 2700 Ch= BRC 2000

Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463551) Television Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463546) Television
Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463553) Television Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463545) Television
Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463547) Television Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463549) Television
Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463550) Television Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463552) Television
Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463554) Television Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 1746801) Television
Use red slider bar for more.
Colourmaster 2700 Ch= BRC 2000; His Master's Voice (ID = 463551) Television
His Master's Voice: Colourmaster 2700 Ch= BRC 2000 [Television] ID = 463551 800x500
Select picture or schematic to display from thumbnails on the right and click for download.
For model Colourmaster 2700 Ch= BRC 2000, His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB:
By courtesy of UK ebay user idcards_no! from 7th june 2008.

Country:  Great Britain (UK)
Manufacturer / Brand:  His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Year: 1968 Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: A63-11X
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Colourmaster 2700 Ch= BRC 2000 - His Master's Voice Masters,
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 850 x 830 x 410 mm / 33.5 x 32.7 x 16.1 inch
Notes HMV Colourmaster 2700; "The worlds first all-transistor (color) TV", 25" dual standard 405 lines VHF b/w, 625 lines UHF PAL colour TV, similar transistorized Thorn BRC 2000 chassis have been used also in other early british colour TVs. Six channel presets, tint control! Cabinet with full-length doors.
Price in first year of sale 362.00 £
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.
