Compact Q5

Compact Q5; His Master's Voice (ID = 2114820) Car Radio
Use red slider bar for more.
Compact Q5; His Master's Voice (ID = 2114820) Car Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW
Year: 1962 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 4: 6DS8 6DS8 6DR8 6ET6
Semiconductors (the count is only for transistors) 1: OC26
Main principle Superhet with RF-stage; ZF/IF 470 kHz; 3 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12-14 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Compact Q5 - His Master's Voice HMV, H.M.V.
Material Metal case
Shape Chassis only or for «building in»
Price in first year of sale 49.95 AUS £
Literature/Schematics (1) - - Manufacturers Literature (HMV Service Manual for Models Q1, Q4, Q5, Q6, Q7, R1, R4 & R6.)
Literature/Schematics (2) J.R. Publications Car Radio Service Handbook (Vol. 1, Page H10.)

Model page created by Martin Kent. See "Data change" for further contributors.
