For model Viking TG-40 Ch= TG, His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW:
..facebook.com/marketplace/item/521363441994547/

Country:  Australia
Manufacturer / Brand:  His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW
Year: 1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: BF195 BF194 BF194 BC149 BC158 OC987 OC988 OC987 OC988 BY126 OA90 OA90
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 240-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Viking TG-40 Ch= TG - His Master's Voice HMV, H.M.V.
Material Wooden case, TUBES VISIBLE.
Shape Console with any shape - in general
Dimensions (WHD) 29.125 x 21.7 x 16.25 inch / 740 x 551 x 413 mm
Net weight (2.2 lb = 1 kg) 39 lb 8 oz (39.5 lb) / 17.933 kg
Price in first year of sale 159.00 AUS $
Literature/Schematics (1) - - Manufacturers Literature (HMV Service Manual for Models TG-4M & TG-40.)
Literature/Schematics (2) J.R. Publications Transistor Radio Service Handbook (Group G8, 1971-72, Page H67.)

Model page created by Martin Kent. See "Data change" for further contributors.
