AM-FM Stereo Receiver SR-2010

AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 1716297) Radio AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 1292757) Radio
AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 1470089) Radio AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 2322918) Radio
AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 2322919) Radio AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 2322920) Radio
AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 2322921) Radio AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 2322922) Radio
AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 2322923) Radio AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 2322924) Radio
Use red slider bar for more.
AM-FM Stereo Receiver SR-2010; Hitachi Ltd.; Tokyo (ID = 1716297) Radio
Hitachi Ltd.; Tokyo: AM-FM Stereo Receiver SR-2010 [Radio] ID = 1716297 933x339
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM-FM Stereo Receiver SR-2010, Hitachi Ltd.; Tokyo:
aus Hitachi HiFi Prospekt 1980/81

Country:  Japan
Manufacturer / Brand:  Hitachi Ltd.; Tokyo
alternative name

Hitachi Sales Corp. of America
Year: 1979–1982 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out 80 W (unknown quality)
from Radiomuseum.org Model: AM-FM Stereo Receiver SR-2010 - Hitachi Ltd.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 435 x 110 x 290 mm / 17.1 x 4.3 x 11.4 inch
Notes Hitachi AM-FM Stereo Receiver Model SR-2010.
2 Band Receiver with 2x 40 watts into 8 Ohms 20 - 20000Hz at THD 0,02%.
Bass-, Treble and Loudness Control.
Inputs Phono, Tape.
Power Consumption 125 watts.
Design Silver.
Net weight (2.2 lb = 1 kg) 6.5 kg / 14 lb 5.1 oz (14.317 lb)
Source of data - - Data from my own collection

Model page created by Franz Scharner. See "Data change" for further contributors.
