AM-FM Stereo Receiver SR-503L

Hitachi Ltd.; Tokyo

  • Year
  • 1978 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 359931
    • alternative name: Hitachi Sales Corp. of America

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz, 100; 117; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 40 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: AM-FM Stereo Receiver SR-503L - Hitachi Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 435 x 144 x 359 mm / 17.1 x 5.7 x 14.1 inch
  • Notes
  • The SR-503L was manufactured in Japan between 1977 and 1978 and features a silver or black finish. It includes a range of inputs and outputs, supports FM, MW, and LW tuning, and has a power output of 20 watts per channel into 8Ω (stereo).

    It is the same as the SR-503 with the addition of Longwave.



  • Net weight (2.2 lb = 1 kg)
  • 7.6 kg / 16 lb 11.8 oz (16.74 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual SR-503, SR-603, No. 108)
  • Author
  • Model page created by Peter Liska. See "Data change" for further contributors.
