Car Stereo 8 CS-1750IC

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629160) R-Player

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629161) R-Player

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629162) R-Player

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629163) R-Player

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629164) R-Player

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629165) R-Player

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629166) R-Player

Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1629167) R-Player
Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1591776) R-Player Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1591812) R-Player
Use red slider bar for more.
Car Stereo 8 CS-1750IC; Hitachi Ltd.; Tokyo (ID = 1591776) R-Player
Hitachi Ltd.; Tokyo: Car Stereo 8 CS-1750IC [R-Player] ID = 1591776 933x624
Select picture or schematic to display from thumbnails on the right and click for download.
For model Car Stereo 8 CS-1750IC, Hitachi Ltd.; Tokyo:
Hitachi Katalog 1973 - Seite 24

Country:  Japan
Manufacturer / Brand:  Hitachi Ltd.; Tokyo
alternative name

Hitachi Sales Corp. of America
Year: 1973 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 16 W (unknown quality)
from Radiomuseum.org Model: Car Stereo 8 CS-1750IC - Hitachi Ltd.; Tokyo
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 71 x 190 inch / 4572 x 1803 x 4826 mm
Notes

Hitachi 8-Spur-Stereo-Player mit Programmwähler Model CS-1750IC.
30 - 12.000 Hz
Automatischer Rück-Schelllauf, Tonblende.
8x Dioden, 2x IC's, 6x Varistor

Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Literature/Schematics (1) -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
