Car Stereo Autoradio KMS-2300E

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633835) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633836) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633837) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633839) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633840) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633841) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633842) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633843) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633844) Car Radio

Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633845) Car Radio
Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633385) Car Radio
Use red slider bar for more.
Car Stereo Autoradio KMS-2300E; Hitachi Ltd.; Tokyo (ID = 1633385) Car Radio
Hitachi Ltd.; Tokyo: Car Stereo Autoradio KMS-2300E [Car Radio] ID = 1633385 771x382
Select picture or schematic to display from thumbnails on the right and click for download.
For model Car Stereo Autoradio KMS-2300E, Hitachi Ltd.; Tokyo:
Bild aus Hitachi Service Unterlagen

Country:  Japan
Manufacturer / Brand:  Hitachi Ltd.; Tokyo
alternative name

Hitachi Sales Corp. of America
Year: 1973 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 12 W (unknown quality)
from Radiomuseum.org Model: Car Stereo Autoradio KMS-2300E - Hitachi Ltd.; Tokyo
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 50 x 150 mm / 7.1 x 2 x 5.9 inch
Notes

4-Band Stereo Autoradio, 5 Stationtasten (L, M, K, U,U, DIN-Buchse, Tonblende Ausgangsleistung 2x 6 Watt.

Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Literature/Schematics (1) Hitachi Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
