Car Stereo CS-2400 IC

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632772) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632773) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632774) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632775) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632776) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632777) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632778) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632779) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632780) R-Player

Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632781) R-Player
Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632342) R-Player
Use red slider bar for more.
Car Stereo CS-2400 IC; Hitachi Ltd.; Tokyo (ID = 1632342) R-Player
Hitachi Ltd.; Tokyo: Car Stereo CS-2400 IC [R-Player] ID = 1632342 616x408
Select picture or schematic to display from thumbnails on the right and click for download.
For model Car Stereo CS-2400 IC, Hitachi Ltd.; Tokyo:
Bild aus Hitachi Service Unterlagen

Country:  Japan
Manufacturer / Brand:  Hitachi Ltd.; Tokyo
alternative name

Hitachi Sales Corp. of America
Year: 1974 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Special Tape or Cassette-Format
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 12 W (unknown quality)
from Radiomuseum.org Model: Car Stereo CS-2400 IC - Hitachi Ltd.; Tokyo
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 120 x 50 x 178 mm / 4.7 x 2 x 7 inch
Notes

Haitachi 8 Spur 2 Kanal Stereo-Player mit Bandzählwerk, Model CS-2400 IC 50 bis 10.000 Hz.

Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Literature/Schematics (1) Hitachi Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
