Eliza W-826X
Hitachi Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Hitachi Ltd.; Tokyo
- Year
- 1961–1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 212568
-
- alternative name: Hitachi Sales Corp. of America
- Number of Transistors
- 8
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Dry Batteries / D: 6 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Eliza W-826X - Hitachi Ltd.; Tokyo
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 466 x 152 x 146 mm / 18.3 x 6 x 5.7 inch
- Notes
-
Hitachi Model W826X Transistor Mantel Radio
All transistor (eight) mantel radio. Superheterodyne using push-pull ring-base transistors. PM speaker 6" x 4". This dual wave set may be used as a mantel or wall type. (FROM MINGAY'S PRICE SERVICE)
- Net weight (2.2 lb = 1 kg)
- 3.2 kg / 7 lb 0.8 oz (7.048 lb)
- Price in first year of sale
- 47.25 AUS £
- Source of data
- - - Data from my own collection
- Mentioned in
- Mingay's Price Service (Feb 1962 to Feb 1963.)
- Author
- Model page created by José Manuel Silvestre. See "Data change" for further contributors.
