Belsona TRQ-510

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339642) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339643) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339644) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339645) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339646) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339647) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339648) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339649) R-Player

Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 1339650) R-Player
Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 727027) R-Player
Use red slider bar for more.
Belsona TRQ-510; Hitachi Ltd.; Tokyo (ID = 727027) R-Player
Hitachi Ltd.; Tokyo: Belsona TRQ-510 [R-Player] ID = 727027 695x559
Select picture or schematic to display from thumbnails on the right and click for download.
For model Belsona TRQ-510, Hitachi Ltd.; Tokyo:
Picture taken from service manual

Country:  Japan
Manufacturer / Brand:  Hitachi Ltd.; Tokyo
alternative name

Hitachi Sales Corp. of America
Year: 1965 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 7: 2SB73 2SB75 2SB77 2SB77 2SB77 2SB156 2SB156 1N34 1S310 1S310 1S310 1S310
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Line / Batteries (any type) / 100; 115; 200; 230 / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Belsona TRQ-510 - Hitachi Ltd.; Tokyo
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 280 x 90 x 230 mm / 11 x 3.5 x 9.1 inch
Notes Loudspeaker 4 x 2.5 inch. Tape speeds 3 3/4 ips 1 7/8 ips. Reel 5 inch
Net weight (2.2 lb = 1 kg) 8.4 lb (8 lb 6.4 oz) / 3.814 kg
Source of data - - Manufacturers Literature
Literature/Schematics (1) Radio Bulletin January 1966
