C513 Ch= 115
Hoffman Radio Corp.; Los Angeles, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hoffman Radio Corp.; Los Angeles, CA
- Year
- 1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 44399
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Wave bands
- Broadcast and Short Wave (SW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11.5 inch = 29.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: C513 Ch= 115 - Hoffman Radio Corp.; Los
- Shape
- Console with any shape - in general
- Notes
-
Identical to model B503, but two 6V6 tubes replaced by FOUR 6K6 tubes in parallel push-pull configuration.
AM: 540-1600kc SW: 5.6-10.4Mc and 9.4-19.4Mc
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 21, Copyright 1950
- Mentioned in
- Photofact Folder, Howard W. SAMS (4820-9 Set 50 Folder 9)
