PT1144U Ch= 326U
Hoffman Radio Corp.; Los Angeles, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hoffman Radio Corp.; Los Angeles, CA
- Year
- 1956 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 272509
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 15
- Valves / Tubes
- 4BQ7A 5AT8 2AF4A 5AN8 3DT6 12CU5 or 12C5 3CB6 5U8 6AU8 12L6GT 6CG7 12DQ6 1X2B 12AX4GT 14QP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: PT1144U Ch= 326U - Hoffman Radio Corp.; Los
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The Hoffman model PT1144U is a 14" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 326U, VHF-Tuner 9926, UHF-Tuner 9923 and picture tube 14QP4A.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 329 Folder 18-S dated 9-56)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 371 Folder 4 Dated 9-57)
- Literature/Schematics (2)
- Set 329 Folder 18-S dated 9-56
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
