Isolationsprüfer J2V
Horn, Dr. Theodor; Leipzig
- Country
- Germany
- Manufacturer / Brand
- Horn, Dr. Theodor; Leipzig
- Year
- 1912
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 237284
- Wave bands
- - without
- Power type and voltage
- Solar- and/or muscle driven, also addl. power jack possible
- Loudspeaker
- - - No sound reproduction output.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Isolationsprüfer J2V - Horn, Dr. Theodor; Leipzig
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 200 x 230 x 170 mm / 7.9 x 9.1 x 6.7 inch
- Notes
-
J2V, Isolationsprüfer mit eingebauten Kurbelinduktoren, Prüfspannung: 220 und 440 V.
Ausführungen mit verschiedenen Skalenbereichen:
- bis. max. 125 V (Preis: 170,00 RM)
- bis max. 225/450 V (Preis: 220,00 RM)
- bis max. 225 oder 250 V (Preis: 175,00 RM)
- bis max. 450 oder 500 V (Preis: 180,00 RM)
- bis max. 125/250 oder 500 V (Preis: 210,00 RM)
- bis max. 125/250 V (Preis: 210,00 RM)
- bis max. 225/500 V (Preis: 225,00 RM)
- bis max. 225/500 V, normal sp. 220/440 V (Preis: 225,00 RM)
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Price in first year of sale
- 170.00 RM
- Source of data
- -- Original-techn. papers.
- Mentioned in
- -- Original prospect or advert
- Literature/Schematics (4)
- Isolationsprüfer mit eingebauten Kurbelinduktoren. Montage- und Tascheninstrumente. Leipzig 1912.
