• Year
  • 1980 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 197413

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 100; 120; 220; 240 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Oscilloscope OS-650 - Hung Chang Co. Ltd., Protek;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 280 x 145 x 422 mm / 11 x 5.7 x 16.6 inch
  • Notes
  • 50 MHz Dual Trace Oscilloscope; CRT 10 x 8 cm;
    Vertical: 1 mV/Div - 5 V/Div ;
    Horizontal: 200 nS/Div - 0.5 S/Div
  • Net weight (2.2 lb = 1 kg)
  • 9.8 kg / 21 lb 9.4 oz (21.586 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Ottmar Rollmann. See "Data change" for further contributors.
