IC4008A

IC4008A; Icom, Inoue (ID = 1947636) Amateur

IC4008A; Icom, Inoue (ID = 1947637) Amateur

IC4008A; Icom, Inoue (ID = 1947640) Amateur

IC4008A; Icom, Inoue (ID = 1947653) Amateur

IC4008A; Icom, Inoue (ID = 1947655) Amateur

IC4008A; Icom, Inoue (ID = 1947874) Amateur

IC4008A; Icom, Inoue (ID = 1947875) Amateur

IC4008A; Icom, Inoue (ID = 1947876) Amateur

IC4008A; Icom, Inoue (ID = 1947877) Amateur

IC4008A; Icom, Inoue (ID = 1947878) Amateur
IC4008A; Icom, Inoue (ID = 1947635) Amateur
Use red slider bar for more.
IC4008A; Icom, Inoue (ID = 1947635) Amateur
Icom, Inoue: IC4008A [Amateur] ID = 1947635 1000x1700
Select picture or schematic to display from thumbnails on the right and click for download.
For model IC4008A, Icom, Inoue Communication Equipment Corp.; Osaka:
Photo issue de la documentation technique ICOM

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 1998 Category: Amateur Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Transceiver; ZF/IF 21700/450 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Storage and/or dry batteries / 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: IC4008A - Icom, Inoue Communication
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 55.5 x 102.5 x 26.5 mm / 2.2 x 4 x 1 inch
Notes

IC4008A version for american market; Frequency range: 433,075 - 434,775 Mhz, 69 channel.

Mode: FM analog voice, 4 kHz deviation (NPSPAC)

IC4008MKII is the italian version.

Net weight (2.2 lb = 1 kg) 0.180 kg / 0 lb 6.3 oz (0.396 lb)

Model page created by Jean-Luc Potart. See "Data change" for further contributors.
