IC-207H

IC-207H; Icom, Inoue (ID = 189932) Amateur
Use red slider bar for more.
IC-207H; Icom, Inoue (ID = 189932) Amateur
Icom, Inoue: IC-207H [Amateur] ID = 189932 800x451
Select picture or schematic to display from thumbnails on the right and click for download.
For model IC-207H, Icom, Inoue Communication Equipment Corp.; Osaka

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 1997 Category: Amateur Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 45050/450 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 13,8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: IC-207H - Icom, Inoue Communication
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 140 x 40 x 185 mm / 5.5 x 1.6 x 7.3 inch
Notes ICOM Mobile-VHF-/UHF-FM-Transceiver IC-207H.
Frequency range: TX (FM): 144-146 / 430-440 MHz; RX (AM/FM): 118-174 / 400-479 MHz; 162 memories; DTMF; CTCSS; 1k2 and 9k6 Packet Radio; Pout: 50 W on 2 m, 35 W on 70 cm.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Price in first year of sale 1'045.00 DM
Collectors' prices
Mentioned in -- Original prospect or advert

Model page created by Iven Müller. See "Data change" for further contributors.
