IC-245E

IC-245E; Icom, Inoue (ID = 242407) Amateur IC-245E; Icom, Inoue (ID = 242408) Amateur
IC-245E; Icom, Inoue (ID = 425453) Amateur IC-245E; Icom, Inoue (ID = 425454) Amateur
IC-245E; Icom, Inoue (ID = 425455) Amateur IC-245E; Icom, Inoue (ID = 967004) Amateur
IC-245E; Icom, Inoue (ID = 967005) Amateur IC-245E; Icom, Inoue (ID = 967006) Amateur
IC-245E; Icom, Inoue (ID = 967008) Amateur
Use red slider bar for more.
IC-245E; Icom, Inoue (ID = 242407) Amateur
Icom, Inoue: IC-245E [Amateur] ID = 242407 900x622
Select picture or schematic to display from thumbnails on the right and click for download.
For model IC-245E, Icom, Inoue Communication Equipment Corp.; Osaka:
Ausschnitt aus Titelseite cq-DL 07/1978. (bearbeitet)

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 1977 ?? Category: Amateur Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) 132:
Main principle Superhet, double/triple conversion; ZF/IF 10700/455 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 13.8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: IC-245E - Icom, Inoue Communication
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 155 x 90 x 235 mm / 6.1 x 3.5 x 9.3 inch
Notes ICOM Mobile-VHF-Allmode-Transceiver IC-245E.
Frequency range: 144-146 MHz; Pout: 10 W.
Net weight (2.2 lb = 1 kg) 2.6 kg / 5 lb 11.6 oz (5.727 lb)
Price in first year of sale 1'595.00 DM
Collectors' prices
Source of data -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
