IC-28H

IC-28H; Icom, Inoue (ID = 1908809) Amateur IC-28H; Icom, Inoue (ID = 1908811) Amateur
IC-28H; Icom, Inoue (ID = 1908812) Amateur
Use red slider bar for more.
IC-28H; Icom, Inoue (ID = 1908809) Amateur
Icom, Inoue: IC-28H [Amateur] ID = 1908809 965x762
Select picture or schematic to display from thumbnails on the right and click for download.
For model IC-28H, Icom, Inoue Communication Equipment Corp.; Osaka

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 1988 ? Category: Amateur Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 13,8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: IC-28H - Icom, Inoue Communication
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 140 x 50 x 180 mm / 5.5 x 2 x 7.1 inch
Notes ICOM Mobil-VHF-FM-Transceiver IC-28H.
Frequenzbereich: 144-146 MHz im 12,5-kHz-Raster; 21 Speicher; 1750-Hz-Rufton; Pout: 45 W/5 W.
Als IC-28E mit Pout: 25 W.
Collectors' prices
Mentioned in RICOFUNK-Katalog 1988

Model page created by Iven Müller. See "Data change" for further contributors.
