• Country
• Japan

• Manufacturer / Brand
• Icom, Inoue Communication Equipment Corp.; Osaka

• Year
• 1985

• Category
• Amateur TRX: Transmitter/Receiver (and Transceiver)

• Radiomuseum.org ID
• 187690

• • alternative name: INOUE COMM. E. CORP

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Transceiver; ZF/IF 70454/9011/455 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Powered by external power supply or a main unit. / 13,8 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 4 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: HF Transceiver IC-735 - Icom, Inoue Communication

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 241 x 94 x 239 mm / 9.5 x 3.7 x 9.4 inch

• Notes
• ICOM KW-Transceiver IC-735.
  Frequenzbereich RX: 0,1–30 MHz, TX: Alle Afu-Bänder von 1,8–30 MHz; Betriebsarten: SSB, CW, AM und FM; P_out: 100 W.
  Von hinten beleuchtetes LCD-Display; zwei VFOs; Kompressor; Noise-Blanker; Pass-Band-Tuning; Notch-Filter. Maximale Stromaufnahme: 18 A.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Price in first year of sale
• 2,500.00 DM

• Mentioned in
• Beam Amateurfunk-Geräteführer '90

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
