For model IC-751A, Icom, Inoue Communication Equipment Corp.; Osaka:
Immagine presa dal manuale della Casa

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 1986 Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) 82:
Main principle Superhet, double/triple conversion
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / 13.8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: IC-751A - Icom, Inoue Communication
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 306 x 115 x 355 mm / 12 x 4.5 x 14 inch
Notes ICOM HF-Transceiver IC-751A.
Frequency range: RX 0.1-30 MHz, TX 160-10 m HAM bands; Modes: SSB, CW, AM; 32 memories; Pout: 100 W.
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Price in first year of sale 3'800.00 DM
Source of data - - Manufacturers Literature
Mentioned in RICOFUNK-Katalog 1988
Literature/Schematics (1) Beam Amateurfunk-Geräteführer '90

Model page created by Gualtiero Fosella. See "Data change" for further contributors.



All listed radios etc. from Icom, Inoue Communication Equipment Corp.; Osaka
Here you find 296 models, 187 with images and 54 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Icom, Inoue: IC-751A
Threads: 1 | Posts: 1
Hits: 2481     Replies: 0
icom: IC-751A;
Gualtiero Fosella
08.Jan.09
  1

La Casa forniva anche un alimentatore a 220V CA del tipo switching (IC-PS35), che poteva essere montato all'interno dell' apparato.
