- Country
- Japan
- Manufacturer / Brand
- Icom, Inoue Communication Equipment Corp.; Osaka
- Year
- 1996
- Category
- Amateur TRX: Transmitter/Receiver (and Transceiver)
- Radiomuseum.org ID
- 73524
-
- alternative name: INOUE COMM. E. CORP
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet, double/triple conversion
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Powered by external power supply or a main unit. / DC 13.8 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2.6 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: IC-756 - Icom, Inoue Communication
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 340 x 111 x 285 mm / 13.4 x 4.4 x 11.2 inch
- Notes
- ICOM HF-/VHF-Transceiver IC-756.
Frequency range: TX 160-6 m incl. WARC, RX 0.03-60 MHz; Modes: SSB, CW, AM, FM, RTTY; 99 memories; Pout: 5···100 W (AM 5···40 W).
- Net weight (2.2 lb = 1 kg)
- 10.5 kg / 23 lb 2 oz (23.128 lb)
- Mentioned in
- -- Original prospect or advert
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
