• Year
  • 1999
  • Category
  • Amateur TRX: Transmitter/Receiver (and Transceiver)
  • Radiomuseum.org ID
  • 73525
    • alternative name: INOUE COMM. E. CORP

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 64455/455/36 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Powered by external power supply or a main unit. / DC 13.8 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 2.6 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: IC-756PRO - Icom, Inoue Communication
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 320 x 111 x 285 mm / 12.6 x 4.4 x 11.2 inch
  • Notes
  • ICOM HF-/VHF-DSP-Transceiver IC-756PRO.
    Frequency range: TX 160-6 m incl. WARC, RX 0.03-60 MHz; Modes: SSB, AM, FM, CW, RTTY; 99 memories; 5" TFT color display; built-in ATU; built-in CW keyer; 32-Bit-DSP; Pout: 5···100 W (AM 5···40 W).
  • Net weight (2.2 lb = 1 kg)
  • 9.6 kg / 21 lb 2.3 oz (21.145 lb)
  • Price in first year of sale
  • 7,690.00 DM
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Iven Müller. See "Data change" for further contributors.
