IC-R70

IC-R70; Icom, Inoue (ID = 281310) Amateur-R

IC-R70; Icom, Inoue (ID = 281311) Amateur-R

IC-R70; Icom, Inoue (ID = 1949668) Amateur-R

IC-R70; Icom, Inoue (ID = 1949669) Amateur-R

IC-R70; Icom, Inoue (ID = 1949670) Amateur-R

IC-R70; Icom, Inoue (ID = 1949671) Amateur-R

IC-R70; Icom, Inoue (ID = 1949672) Amateur-R

IC-R70; Icom, Inoue (ID = 1949674) Amateur-R

IC-R70; Icom, Inoue (ID = 1949675) Amateur-R

IC-R70; Icom, Inoue (ID = 1949679) Amateur-R
IC-R70; Icom, Inoue (ID = 58897) Amateur-R IC-R70; Icom, Inoue (ID = 72882) Amateur-R
IC-R70; Icom, Inoue (ID = 197096) Amateur-R IC-R70; Icom, Inoue (ID = 197097) Amateur-R
IC-R70; Icom, Inoue (ID = 197098) Amateur-R IC-R70; Icom, Inoue (ID = 197099) Amateur-R
IC-R70; Icom, Inoue (ID = 197100) Amateur-R IC-R70; Icom, Inoue (ID = 197101) Amateur-R
IC-R70; Icom, Inoue (ID = 255432) Amateur-R IC-R70; Icom, Inoue (ID = 1398479) Amateur-R
Use red slider bar for more.
IC-R70; Icom, Inoue (ID = 58897) Amateur-R
Icom, Inoue: IC-R70 [Amateur-R] ID = 58897 879x363
Select picture or schematic to display from thumbnails on the right and click for download.
For model IC-R70, Icom, Inoue Communication Equipment Corp.; Osaka:
KW-Empfänger ICOM IC-R70

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 1982–1984 Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Semiconductors (the count is only for transistors) 94:
Main principle Superhet, double/triple conversion
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 100; 117; 230 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: IC-R70 - Icom, Inoue Communication
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 286 x 111 x 276 inch / 7264 x 2819 x 7010 mm
Notes ICOM IC-R70.
ICs: 45.
Vierfachsuper mit stetig regelbarem ZF-Durchlassbereich. Allbandempfänger von 100 kHz bis 30 MHz durchgehend; 2 VFOs. Frequenzaufbereitung: CPU-gesteuerter PLL-Synthesizer in 10-Hz-Schritten. Betriebsarten AM, FM, SSB, CW, RTTY.
Net weight (2.2 lb = 1 kg) 7.4 kg / 16 lb 4.8 oz (16.3 lb)
Price in first year of sale 2'430.00 DM
Collectors' prices
Source of data -- Collector info (Sammler)
Mentioned in Shortwave Receivers - Past & Present (3rd ed.) (RICOFUNK-Katalog 1984)
Literature/Schematics (1) Shortwave-Receivers Past & Present

Model page created by Werner Raacke. See "Data change" for further contributors.
