IC-V82

IC-V82; Icom, Inoue (ID = 823535) Amat TRX
Use red slider bar for more.
IC-V82; Icom, Inoue (ID = 823535) Amat TRX
Icom, Inoue: IC-V82 [Amat TRX] ID = 823535 185x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model IC-V82, Icom, Inoue Communication Equipment Corp.; Osaka:
FA 2/05

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 2005 Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 46350/450 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage and/or dry batteries / 7,2; 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.3 W (unknown quality)
from Radiomuseum.org Model: IC-V82 - Icom, Inoue Communication
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 54 x 139 x 37 mm / 2.1 x 5.5 x 1.5 inch
Notes ICOM VHF-FM-Handfunkgerät mit Digitalmodus (optionale Digitaleinheit erforderlich) IC-V82.
Frequenzbereich: 144...146 MHz; Pout: 7 W.
Betriebsspannung: 7,2 V (NiCd-Akku), 9 V (6× 1,5 V AA-Batterien) oder 6...10,3 V bei externer Speisung; Anschlussmöglichkeit für PC oder GPS-Empfänger über RS232; 207 Speicher; Frequenz-, Kanalanzeige oder Anzeige einer alphanumerischen Bezeichnung im Display möglich; CTCSS- und DTCS-Funktion; DTMF-Coder eingebaut, optionaler DTMF-Decoder nachrüstbar; TOT- und APO-Funktion.
Net weight (2.2 lb = 1 kg) 0.370 kg / 0 lb 13 oz (0.815 lb)
Price in first year of sale 199.00 EUR
Collectors' prices
Mentioned in FA 2/05

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
