KW-Transceiver IC-707

KW-Transceiver IC-707; Icom, Inoue (ID = 784720) Amat TRX KW-Transceiver IC-707; Icom, Inoue (ID = 784721) Amat TRX
Use red slider bar for more.
KW-Transceiver IC-707; Icom, Inoue (ID = 784720) Amat TRX
Icom, Inoue: KW-Transceiver IC-707 [Amat TRX] ID = 784720 750x316
Select picture or schematic to display from thumbnails on the right and click for download.
For model KW-Transceiver IC-707, Icom, Inoue Communication Equipment Corp.; Osaka:
ebay-VK: snowboardmoe

Country:  Japan
Manufacturer / Brand:  Icom, Inoue Communication Equipment Corp.; Osaka
alternative name

INOUE COMM. E. CORP
Year: 1994 ?? Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / 13,8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.6 W (unknown quality)
from Radiomuseum.org Model: KW-Transceiver IC-707 - Icom, Inoue Communication
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 240 x 95 x 239 mm / 9.4 x 3.7 x 9.4 inch
Notes Frequenzbereich Senden und Empfang:
Alle neun Amateurfunkbänder 500 kHz - 30 MHz.
Betriebsarten: USB, LSB, AM, FM, mit option UI-9.
Net weight (2.2 lb = 1 kg) 4.1 kg / 9 lb 0.5 oz (9.031 lb)
Collectors' prices
Literature/Schematics (1) Amateurfunk - Geräteführer 1996

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
