Low Tension Battery Potentiometer 300Ω

Low Tension Battery Potentiometer 300Ω; Igranic Electric, (ID = 2477425) Radio part Low Tension Battery Potentiometer 300Ω; Igranic Electric, (ID = 2477426) Radio part
Low Tension Battery Potentiometer 300Ω; Igranic Electric, (ID = 2477427) Radio part Low Tension Battery Potentiometer 300Ω; Igranic Electric, (ID = 2477428) Radio part
Low Tension Battery Potentiometer 300Ω; Igranic Electric, (ID = 2477429) Radio part Low Tension Battery Potentiometer 300Ω; Igranic Electric, (ID = 2477430) Radio part
Use red slider bar for more.
Low Tension Battery Potentiometer 300Ω; Igranic Electric, (ID = 2477425) Radio part
Igranic Electric,: Low Tension Battery Potentiometer 300Ω [Radio part] ID = 2477425 1399x1635
Select picture or schematic to display from thumbnails on the right and click for download.
For model Low Tension Battery Potentiometer 300Ω, Igranic Electric, Bedford:
Side view.

Country:  Great Britain (UK)
Manufacturer / Brand:  Igranic Electric, Bedford
Year: 1924 ?? Category: Radio part (not a module)
Details
Loudspeaker
Power out
from Radiomuseum.org Model: Low Tension Battery Potentiometer 300Ω - Igranic Electric, Bedford
Material Various materials
Dimensions (WHD) 60 x 80 x 50 mm / 2.4 x 3.1 x 2 inch
Notes

Low Tension Battery potentiometer, for adjusting the current in the valve heaters, 300Ω.

Price in first year of sale 0.35 GB £
Mentioned in -- Collector info (Sammler)

Model page created by Gary Cowans. See "Data change" for further contributors.
