MA90

MA90; Avialex; Montreuil (ID = 801409) R-Player MA90; Avialex; Montreuil (ID = 801410) R-Player
MA90; Avialex; Montreuil (ID = 801798) R-Player MA90; Avialex; Montreuil (ID = 801799) R-Player
MA90; Avialex; Montreuil (ID = 801800) R-Player MA90; Avialex; Montreuil (ID = 890795) R-Player
Use red slider bar for more.
MA90; Avialex; Montreuil (ID = 801409) R-Player
Avialex; Montreuil: MA90 [R-Player] ID = 801409 900x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model MA90, Avialex; Montreuil sous Bois

Country:  France
Manufacturer / Brand:  Avialex; Montreuil sous Bois
Year: 1959 Category: Sound/Video Recorder and/or Player
Valves / Tubes 3: 6CN8 12AX7 6EX6
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out
from Radiomuseum.org Model: MA90 - Avialex; Montreuil sous Bois
Material Modern plastics (no Bakelite or Catalin)
Dimensions (WHD) 275 x 180 x 140 mm / 10.8 x 7.1 x 5.5 inch
Notes 2 pistes, vitesse 9.5cm/s, diamètre des bobines 10cm, 1 moteur.
Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
Price in first year of sale 39'900.00 francs

Model page created by Christian Berthier. See "Data change" for further contributors.



All listed radios etc. from Avialex; Montreuil sous Bois
Here you find 4 models, 4 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
