Gigant 32

Gigant 32; Ingelen, (ID = 26182) Radio
Gigant 32; Ingelen, (ID = 73641) Radio Gigant 32; Ingelen, (ID = 1670404) Radio
Gigant 32; Ingelen, (ID = 1670411) Radio Gigant 32; Ingelen, (ID = 1670416) Radio
Gigant 32; Ingelen, (ID = 2003698) Radio Gigant 32; Ingelen, (ID = 2003699) Radio
Use red slider bar for more.
Gigant 32; Ingelen, (ID = 73641) Radio
Ingelen,: Gigant 32 [Radio] ID = 73641 600x674
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gigant 32, Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien:
Ingelen Gigant 32

Country:  Austria
Manufacturer / Brand:  Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Brand

Elektrot.Fabrik Ludwig Neumann
Year: 1932/1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: E455 E424N E415 E455 E424N C443 1561
Main principle Super-Heterodyne (Super in general); ZF/IF 128 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Gigant 32 - Ingelen, Elektrotechnische
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 395 x 465 x 300 mm / 15.6 x 18.3 x 11.8 inch
Notes Export Schweiz
Net weight (2.2 lb = 1 kg) 18.3 kg / 40 lb 4.9 oz (40.308 lb)
Price in first year of sale 698.00 ATS
Collectors' prices
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
