For model Supersix Longwave, Insuline Corp. Of America (ICA); New York City:
Ricardo CH, Auktion Nr. 667691452, Verkäufer Sammy4

Country:  United States of America (USA)
Manufacturer / Brand:  Insuline Corp. Of America (ICA); New York City
Year: 1932 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 58 57 58 55 47 80
Main principle Superhet with RF-stage; ZF/IF 115 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Supersix [Longwave] - Insuline Corp. Of America ICA;
Notes AVC
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Circuit diagram reference Rider's Perpetual, Volume 4 = ca. 1934 and before
Mentioned in The Radio Collector's Directory and Price Guide 1921 - 1965
