International AM/FM Radio D-18

International (virtual brand)

  • Year
  • 1989 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 309251

 Technical Specifications

  • Number of Transistors
  • 8
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Dry Batteries / AA: 2 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
  • Power out
  • 0.5 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: International AM/FM Radio D-18 - International virtual brand
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 70 x 135 x 30 mm / 2.8 x 5.3 x 1.2 inch
  • Notes
  • Altavoz 8 Ω

  • Net weight (2.2 lb = 1 kg)
  • 0.216 kg / 0 lb 7.6 oz (0.476 lb)
  • Price in first year of sale
  • 1,200.00 Pesetas

 Collections | Museums | Literature

Collections

The model International AM/FM Radio is part of the collections of the following members.
