AM/FM Portable Radio TR-30

AM/FM Portable Radio TR-30; Intersound brand (ID = 2465226) Radio AM/FM Portable Radio TR-30; Intersound brand (ID = 2465227) Radio
AM/FM Portable Radio TR-30; Intersound brand (ID = 2465228) Radio AM/FM Portable Radio TR-30; Intersound brand (ID = 2465229) Radio
AM/FM Portable Radio TR-30; Intersound brand (ID = 2465230) Radio AM/FM Portable Radio TR-30; Intersound brand (ID = 2465231) Radio
AM/FM Portable Radio TR-30; Intersound brand (ID = 2465232) Radio AM/FM Portable Radio TR-30; Intersound brand (ID = 2465233) Radio
AM/FM Portable Radio TR-30; Intersound brand (ID = 2465234) Radio AM/FM Portable Radio TR-30; Intersound brand (ID = 2465235) Radio
Use red slider bar for more.
AM/FM Portable Radio TR-30; Intersound brand (ID = 2465226) Radio
Intersound brand: AM/FM Portable Radio TR-30 [Radio] ID = 2465226 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM/FM Portable Radio TR-30, Intersound (brand)

Country:  Switzerland
Manufacturer / Brand:  Intersound (brand)
Year: 1990 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) TA2132 TDA2822
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 230 or C: 3 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: AM/FM Portable Radio TR-30 - Intersound brand
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 220 x 120 x 60 mm / 8.7 x 4.7 x 2.4 inch
Notes

This radio should be later than the 3-transistor TR-30 since there are no transistors but only two integrated circuits: TA2132P for radio and intermediate frequency and UTC2822 for audio frequency.

Model page created by Aldo Andreani. See "Data change" for further contributors.



All listed radios etc. from Intersound (brand)
Here you find 25 models, 24 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
