Leman 5325

Leman 5325; Invicta Radio, (ID = 1746672) Radio Leman 5325; Invicta Radio, (ID = 1746676) Radio
Leman 5325; Invicta Radio, (ID = 1746680) Radio Leman 5325; Invicta Radio, (ID = 1746685) Radio
Leman 5325; Invicta Radio, (ID = 1746692) Radio Leman 5325; Invicta Radio, (ID = 1746702) Radio
Leman 5325; Invicta Radio, (ID = 1961215) Radio
Use red slider bar for more.
Leman 5325; Invicta Radio, (ID = 1746672) Radio
Invicta Radio,: Leman 5325 [Radio] ID = 1746672 1024x576
Select picture or schematic to display from thumbnails on the right and click for download.
For model Leman 5325, Invicta Radio, Barcelona

Country:  Spain
Manufacturer / Brand:  Invicta Radio, Barcelona
alternative name

Establecimientos Lucarda || Radio Lucarda, S.L
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: HCH81 HF93 HBC91 HL94 HY90
Main principle Superheterodyne (common)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage AC/DC-set / 125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Leman 5325 - Invicta Radio, Barcelona
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 320 x 200 x 170 mm / 12.6 x 7.9 x 6.7 inch
Notes

Este modelo es en un 90% en diagrama y valores de componentes al  invicta 5324.

Price in first year of sale 2'495.00 ESP
Mentioned in Anuncio La Vanguardia Española marzo 1958

Model page created by Antonio Gamez-Martinez. See "Data change" for further contributors.
