Cassette-Stereo TS-720 Ch=2880201; ITT Schaub-Lorenz (ID = 113594) Car Radio
ITT Schaub-Lorenz: Cassette-Stereo TS-720 Ch=2880201 [Car Radio] ID = 113594 933x439
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cassette-Stereo TS-720 Ch=2880201, ITT Schaub-Lorenz:
Serien Nr.229697

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1975 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Cassette-Stereo TS-720 Ch=2880201 - ITT Schaub-Lorenz
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 178 x 42 x 140 mm / 7 x 1.7 x 5.5 inch
Notes Kassette Stereo mit Endabschaltung teilweise IC Bestückung
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Price in first year of sale 435.00 DM
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Funk-Technik (FT) (19/1975, S. 627 / Neuvorstellung)

Model page created by Jörg Kulbe. See "Data change" for further contributors.
