Cassetten-Deck HiFi 8022

ITT Schaub-Lorenz

  • Year
  • 1980
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 153530

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 127 / 220/240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Cassetten-Deck HiFi 8022 - ITT Schaub-Lorenz
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 480 x 105 x 350 mm / 18.9 x 4.1 x 13.8 inch
  • Notes
  • Frontloading 2-Head Stereo Cassette Deck with Dolby B and Ferro-Chrome Tape Capability.
    Auto Shutoff (Full), Mechanical Tape Loading.
    3-Digit Mechanical Counter, Analog Needle Meters.
  • Net weight (2.2 lb = 1 kg)
  • 8.5 kg / 18 lb 11.6 oz (18.722 lb)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
