Pony 18B

Pony 18B; ITT Schaub-Lorenz (ID = 228909) Radio

Pony 18B; ITT Schaub-Lorenz (ID = 228910) Radio

Pony 18B; ITT Schaub-Lorenz (ID = 1989167) Radio

Pony 18B; ITT Schaub-Lorenz (ID = 1989169) Radio
Pony 18B; ITT Schaub-Lorenz (ID = 223662) Radio Pony 18B; ITT Schaub-Lorenz (ID = 1486656) Radio
Pony 18B; ITT Schaub-Lorenz (ID = 1486657) Radio
Use red slider bar for more.
Pony 18B; ITT Schaub-Lorenz (ID = 223662) Radio
ITT Schaub-Lorenz: Pony 18B [Radio] ID = 223662 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pony 18B, ITT Schaub-Lorenz:
My little ITT Pony 18B ca 1975. As usual with ITT KB radios built in the 1970s, this little radio still works remarkably well.

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1975 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 3: ED1402 ED1702 ED1802 TBA570
Main principle Superheterodyne (common); ZF/IF 468 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 9 cm = 3.5 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Pony 18B - ITT Schaub-Lorenz
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 160 x 110 x 52 mm / 6.3 x 4.3 x 2 inch
Notes Transistors: ST1702L, ED1402B, ST1802L. IC: TBA-570A.
Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Howard Craven. See "Data change" for further contributors.



All listed radios etc. from ITT Schaub-Lorenz
Here you find 759 models, 698 with images and 336 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
