Professional RCX75 66313606

Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 680812) Radio Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 680806) Radio
Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 680807) Radio Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 680809) Radio
Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 680810) Radio Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 680811) Radio
Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 1909635) Radio
Use red slider bar for more.
Professional RCX75 66313606; ITT Schaub-Lorenz (ID = 680812) Radio
ITT Schaub-Lorenz: Professional RCX75 66313606 [Radio] ID = 680812 722x625
Select picture or schematic to display from thumbnails on the right and click for download.
For model Professional RCX75 66313606, ITT Schaub-Lorenz

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1976/1977 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 22:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220-240 / 5 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 7 W (unknown quality)
from Radiomuseum.org Model: Professional RCX75 66313606 - ITT Schaub-Lorenz
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 350 x 250 x 95 mm / 13.8 x 9.8 x 3.7 inch
Notes 2 getrennte Zeigerinstrumente für die Anzeige der Frequenz (UKW/MW und KW/LW) Kombianzeigeinstrument für Tuning/Batterie
Frontseitig können über eine 5-pol Dinbuchse wahlweise ein ext. Mikrofon, ein Plattenspieler oder ein Tonbandgerät angeschlossen werden
Loudness - Schalter, eingebautes Electretmikrofon und ext. Lautsprecher/Kopfhörerausgang.
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
