RC630

RC630; ITT Schaub-Lorenz (ID = 96689) Radio

RC630; ITT Schaub-Lorenz (ID = 96690) Radio

RC630; ITT Schaub-Lorenz (ID = 96691) Radio
RC630; ITT Schaub-Lorenz (ID = 2243018) Radio RC630; ITT Schaub-Lorenz (ID = 2323344) Radio
RC630; ITT Schaub-Lorenz (ID = 2323345) Radio RC630; ITT Schaub-Lorenz (ID = 2323346) Radio
RC630; ITT Schaub-Lorenz (ID = 311690) Radio RC630; ITT Schaub-Lorenz (ID = 335267) Radio
RC630; ITT Schaub-Lorenz (ID = 335266) Radio RC630; ITT Schaub-Lorenz (ID = 837347) Radio
RC630; ITT Schaub-Lorenz (ID = 837348) Radio RC630; ITT Schaub-Lorenz (ID = 837349) Radio
Use red slider bar for more.
RC630; ITT Schaub-Lorenz (ID = 2243018) Radio
ITT Schaub-Lorenz: RC630 [Radio] ID = 2243018 1134x850
Select picture or schematic to display from thumbnails on the right and click for download.
For model RC630, ITT Schaub-Lorenz:
Gerät fürs Reisen gekauft, steht immer noch in Betrieb, nur Bandlaufwerk defekt.

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1976–1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 19:
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz; 5 AF stage(s)
Tuned circuits 7 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110-130; 220-240 / C: 5 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch
Power out 2.2 W (unknown quality)
from Radiomuseum.org Model: RC630 - ITT Schaub-Lorenz
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 310 x 235 x 83 mm / 12.2 x 9.3 x 3.3 inch
Notes ICs: 1.
Auch mit dryfit-PC-Akku zu betreiben.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Collectors' prices
Source of data Handbuch VDRG 1977/1978 / Radiokatalog Band 2, Ernst Erb
Mentioned in Handbuch VDRG 1976/1977
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
