Golf europa 103 52140453

Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2475224) Radio

Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2475225) Radio

Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2475227) Radio

Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2475228) Radio

Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2475230) Radio

Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2475231) Radio
Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2476749) Radio
Use red slider bar for more.
Golf europa 103 52140453; ITT Schaub-Lorenz (ID = 2476749) Radio
ITT Schaub-Lorenz: Golf europa 103 52140453 [Radio] ID = 2476749 1105x781
Select picture or schematic to display from thumbnails on the right and click for download.
For model Golf europa 103 52140453, ITT Schaub-Lorenz Wien:
Bild aus Servicedoku.

Country:  Austria
Manufacturer / Brand:  ITT Schaub-Lorenz Wien
Year: 1972–1974 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: BF125 BF255 BF241 BF241 BF240 BC238 BC308 AC178 AC179 AC117
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 6×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Golf europa 103 52140453 - ITT Schaub-Lorenz Wien
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 317 x 192 x 77 mm / 12.5 x 7.6 x 3 inch
Notes

Stationstaste "Europa" für einen Festsender im Bereich 1000 - 1605 kHz (300 - 187m), welcher von der Gehäuserückseite her eingestellt wird.

Bei ITT Schaub-Lorenz Wien für die EFTA-Freihandelszone erzeugt

Parallelgerät zum GOLF europa 103 - ITT Schaub-Lorenz.

Net weight (2.2 lb = 1 kg) 2.6 kg / 5 lb 11.6 oz (5.727 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
