For model Stereo 5500 HiFi Cassette 5253 02/41, 5253 02/45, ITT Schaub-Lorenz

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1973–1975 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 68:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details Cassette-Recorder or -Player; Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 60 W (undistorted)
from Radiomuseum.org Model: Stereo 5500 HiFi Cassette 5253 02/41, 5253 02/45 - ITT Schaub-Lorenz
Material Modern plastics (no Bakelite or Catalin)
Shape Book-shelf unit.
Dimensions (WHD) 630 x 100 x 290 mm / 24.8 x 3.9 x 11.4 inch
Notes

ICs: 1
Stereo 5500 HiFi Cassette ist ein Stereo-Steuergerät mit Cassetten-Recoder und NF-Verstärker mit 2 Endstufen je 30 Watt Sinus.
/41 Metall-Lock
/45 Schwarz

(Stereo radio, cassette recorder, amplifier, this model requires extermal speakers.
Output power 2 x 30 watts RMS.)

Net weight (2.2 lb = 1 kg) 9.7 kg / 21 lb 5.9 oz (21.366 lb)
External source of data Erb
Source of data Katalog RFP 1973 / Radiokatalog Band 2, Ernst Erb
