Trimension TS812 52880217
ITT Schaub-Lorenz
- Country
- Germany
- Manufacturer / Brand
- ITT Schaub-Lorenz
- Year
- 1975
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 75970
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 13
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 1 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 6 FM circuit(s)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 11-16 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 5 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Trimension TS812 52880217 - ITT Schaub-Lorenz
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 178 x 42 x 140 mm / 7 x 1.7 x 5.5 inch
- Notes
- ICs: TCA440, TBA810AS, CA3089AE, TAA865A, TCA910, CA3090AQ, MC1310.
Compact-Cassette: 4,75 cm/sek., Halbspur.
- Net weight (2.2 lb = 1 kg)
- 1.3 kg / 2 lb 13.8 oz (2.863 lb)
- Source of data
- Radiokatalog Band 2, Ernst Erb
