Viola automatic 101 5242 05 41

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88397) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88398) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88399) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88400) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88408) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88401) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88402) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88403) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88404) Radio

Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 88405) Radio
Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 66115) Radio Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 66116) Radio
Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 66117) Radio Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 381915) Radio
Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 381916) Radio Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 73356) Radio
Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 1387578) Radio Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 2122212) Radio
Use red slider bar for more.
Viola automatic 101 5242 05 41; ITT Schaub-Lorenz (ID = 66115) Radio
ITT Schaub-Lorenz: Viola automatic 101 5242 05 41 [Radio] ID = 66115 841x216
Select picture or schematic to display from thumbnails on the right and click for download.
For model Viola automatic 101 5242 05 41, ITT Schaub-Lorenz

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1970–1973 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF106 AF124 AF137 AF136 AF138 BC252 BC172 AC178 AC179 AC117 B30C400-1
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Viola automatic 101 5242 05 41 - ITT Schaub-Lorenz
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 520 x 105 x 140 mm / 20.5 x 4.1 x 5.5 inch
Notes

Gehäuse mit Nussbaum-Dekor.
Siehe auch Viola automatic 101 5242 05 43 in Schleiflack altweiss.

Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
External source of data Erb
Source of data Handbuch VDRG 1970/1971 / Radiokatalog Band 2, Ernst Erb
Mentioned in Handbuch VDRG 1970/1971
Literature/Schematics (1) HdB d.Rdf-& Ferns-GrH 1971/72
Literature/Schematics (2) HdB d.Rdf-& Ferns-GrH 1972/73
Literature/Schematics (3) -- Original-techn. papers.
