• Country
• United States of America (USA)

• Manufacturer / Brand
• Jackson (The) Electrical Instrument CO., Dayton

• Year
• 1941 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 120382

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 30

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Dynamic Output Tube Tester 633 - Jackson The Electrical

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 220 x 220 x 135 mm / 8.7 x 8.7 x 5.3 inch

• Mentioned in
• - - Data from my own collection

• Author
• Model page created by Gerhard Heigl. See "Data change" for further contributors.
